NEW 4" Diameter

KASTOgripspeed C10 Production Sawing Machine
Fully automatic sawing machine for production cutting of steel bars, includes an automatic loading table with adjustable incline for rounds, squares and rectangles.

Klingelhofer Corporation

Blade Guidance

The heavy blade guard incorporates 3 sets of carbide pads to guide and stabilize the thin saw blades thereby assuring accurate cutting. A power-driven brush with automatic wear adjustment removes chips from the teeth of the saw blade.

graphic Klingelhofer Corporation

Klingelhofer Corporation

Klingelhofer Corporation graphic
Bar Storage Table

The bar support rails are adjustable in height so that round and square bars can be loaded. Hydraulically actuated loading discs gently place one bar at a time onto the infeed track. A bundle unscrambler can also be provided to keep the storage table filled.

Klingelhofer Corporation

Bar Feeder

This gripper-type feeder is used to advance the bar for the desired cut length. It also serves to spread the cut so that the saw blade can retract without contacting the cut surface. The gripper is also used for making an automatic trim cut. Long cut lengths can be programmed by multiple indexing.

Klingelhofer Corporation

Klingelhofer Corporation

Klingelhofer Corporation graphic
Touch Screen

All machine functions and programming are managed by means of the "KASTOeasycontrol" touch screen. Such functions as cut length, quantities, blade speeds and feeds, feed stroke, and fault diagnostics are included.

Klingelhofer Corporation

Bundle Unscramblers

A bundle unscrambler can be added to our sawing machines. This enables loading of bundles of bars into a cradle. Chain operated feeders then separate and convey the bars to the escapement area. From there, the loading discs transfer one bar at a time onto the infeed roller track.

graphic Klingelhofer Corporation
For round bars or tubes up to 4,000 lb. bundles.

Klingelhofer Corporation
For round bars or tubes up to 11,000 lb. bundles. Also available for squares and rectangles.

Download the KASTOgripspeed C10 Production Sawing Machines technical sheet. (PDF)
